Finder 41.52.6.012.4016 PCB Relay 12V DC 8A 2 change-overs 1 piece CE rated

The Finder 41.52.6.012.4016 is a PCB relay with a 12 V DC coil and an 8 A switching capacity. It features 2 change-over contacts, making it suitable for applications requiring circuit switching. This relay is commonly used in electronic and industrial automation systems for reliable signal and power management.

Coil Voltage	12V DC
Contact Configuration	2CO (DPDT)
Switching Current	8A
Coil Resistance	220O
Complete with socket	false
Connection	Solder pins
Contact Material	AgSnO2
Control Mode	Bistable, 2 Coils
Degree of protection (IP)	N/A
Depth	29mm
Dimensions	(L x W x H) 29 x 12.5 x 15.7 mm
Drive, polarization	Polarized
Drive, switching attitude	Bistable
Height	15.7mm
Length	29.0mm
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Max. pick-up Voltage	13.2V DC
Max. switching capacity	2000VA
Max. temperature	+85°C
Min. pick-up Voltage	8.4V DC
Minimum Temperature	-40°C
Mounting Type	PCB
Nominal Current	8A
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	2
Number of contacts as normally open contact	2
Rated control supply voltage DC	12 - 12V
Switching Voltage Max	400V AC
Type	PCB relay
Type of electric connection	PCB connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	12.5mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	false
