Finder 40.52.7.012.5000 PCB Relay 12V DC 8A 2 change-overs RT II

The Finder 40.52.7.012.5000 is a PCB relay designed for 12 V DC operation with an 8 A switching capacity and two change-over contacts. It is ideal for use in various electronic applications where reliable switching tasks are required. Commonly applied in automation, control panels, and industrial equipment, this single-piece relay ensures dependable performance on printed circuit boards.

Coil Voltage	12V DC
Contact Configuration	2CO (DPDT)
Switching Current	8A
Complete with socket	false
Degree of protection (IP)	N/A
Depth	29mm
Dimensions	(W x H x D) 12.4 x 25 x 29 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	25mm
IP Rating	IP20
Length	29.0mm
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Gold
Mounting Type	PCB
Nominal Current	8A
Number of contacts as change-over contact	2
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	12 - 12V
Type	PCB relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	12.4mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	false
