The Extech EX505A is a versatile handheld digital multimeter capable of measuring up to CAT IV 600 V. This device features a 6000-count display for precise voltage, current, and frequency readings. Ideal for both professional electricians and DIY enthusiasts, it is suited for electrical testing and troubleshooting tasks.
| Type |
Handheld multimeter |
| A AC reading range (min.) |
0.1µA |
| A DC reading range (max.) |
10A |
| Amperage reading range AC (max.) |
10A |
| Amperage reading range DC (min.) |
0.1µA |
| Basic accuracy |
0.5% |
| Calibrated to |
Manufacturer's standards (no certificate) |
| Current reading |
AC/DC |
| Dim |
(L x W x H) 55 x 83 x 183 mm |
| Display |
Digital |
| Display (counts) |
6000 |
| Frequency reading range |
0.001 Hz -10MHz |
| Height |
183mm |
| Interfaces |
none |
| Length |
55mm |
| Measurement type (details) |
True RMS |
| Misc Attribute |
Extech EX505A |
| Power supply (details) |
9 V battery pack |
| Reading category |
CAT IV 600 V |
| Reading range - capacity |
0.01 nF - 99.99mF |
| Reading range - resistance |
0.1 Ω - 60MΩ |
| Temperature reading range (max.) |
+760°C |
| Temperature reading range (min.) |
-20°C |
| V AC reading range (max.) |
1000V |
| V AC reading range (min.) |
0.01mV |
| Voltage DC reading range (max.) |
1000V |
| Voltage metering |
AC/DC |
| Voltage reading range DC (min.) |
0.01mV |
| Weight |
365g |
| Width |
83mm |
