econ connect ICFG18 IC socket 18 pins 7.62 mm contact spacing

Econ Connect ICFG18 is an 18-pin integrated circuit (IC) socket designed to accommodate dual in-line package (DIP) components with a contact spacing of 7.62 mm. This standard IC socket facilitates reliable and convenient insertion and removal of IC components, enhancing maintenance and prototyping processes in electronic assemblies. It is particularly suited for applications requiring durable and robust connections in developmental and testing environments, such as circuit prototyping and PCB assembly. The IC socket is geared towards ensuring stable and secure connections, making it an essential component for engineers involved in designing and testing electronic circuits.

Number of Positions	18
Pitch	2.54mm
Row Pitch	7.62mm
Content	1
Cross Section	7.62mm
Dimensions	(L x W) 22.86 mm x 10.16 mm
Length	22.86mm
Material	Thermoplastic
Max. temperature	105°C
Maximum Temperature	105°C
Min. temperature	-20°C
Minimum Operating Temperature	-20°C
Number of pins	18
Type	IC socket
Width	10.16mm
