econ connect BL5/1G8 SIL Socket 5 pins/row 1 row standard 1pc

Image Representative of Range

econ connect BL5/1G8 SIL Socket 5 pins/row 1 row standard 1pc

econ connect
Standard range
Order Code:

02-6972

Brand: econ connect MPN: BL5/1G8
Qty Unit Price (Ex VAT)
1+ £0.129
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
351 in stock, despatched in 4 working days

econ connect manufactures the SIL socket BL5/1G8, featuring one row with five pins. This standard receptacle is ideal for applications requiring compact and straightforward connectivity solutions. Commonly used in electronics projects, it provides reliable connections for small-scale or prototype circuits.
Case material PBT
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector type Power strip, straight
Contact material Copper alloy
Contact surface Gold plated
CS 2.54mm
Dim (L x W x H) 13.20 x 11.50 x 2.54 mm
Factory colour Black
Height 2.54mm
Industrial packaging No
Length 13.20mm
Manufacturer part # BL5/1G8
Max. temperature +105°C
Min. temperature -40°C
Misc Attribute Econ Connect
No. of rows 1
Nominal current 1A
Nominal current - rounded value 1A
Nominal voltage 500V AC
Pin length (PCB) 3mm
Pin shape Rectangular
Pins per row 5
RoHS-compliant Yes
Separable No
Total number of pins 5
Type Receptacles (standard)
Width 11.50mm
