The Eaton DILM32-10(230V50/60HZ) electrical contactor is designed for efficient 3-phase motor control up to 15 kW. It is manufactured for reliable switching performance in industrial applications. Ideal for machinery and equipment operation, this contactor supports seamless motor function in various environments.
| Type |
Electrical contactor |
| Auxiliary contact type |
1 maker |
| Connection |
Screws |
| Contact type |
3 makers |
| Control voltage (max.) |
230V AC |
| Control voltage range |
230 V AC (max) |
| Depth |
97mm |
| Height |
85mm |
| Misc Attribute |
DILM32-10(230V50/60HZ) |
| No. of pins |
3-pin |
| Number of auxiliary contacts as normally closed contact |
0 |
| Number of auxiliary contacts as normally open contact |
1 |
| Number of normally closed contacts as main contact |
0 |
| Number of normally open contacts as main contact |
3 |
| Operating voltage AC 50 Hz |
24-690V |
| Operating voltage AC 60 Hz |
24-690V |
| Power |
15kW |
| Rated control supply voltage AC 50 Hz |
230-230V |
| Rated control supply voltage AC 60 Hz |
230-230V |
| Rated control supply voltage DC |
0-0V |
| Rated operation current Ie at AC-1, 400 V |
45A |
| Rated operation current Ie at AC-3, 400 V |
32A |
| Rated operation current Ie at AC-4, 400 V |
15A |
| Rated operation power at AC-3, 400 V |
15kW |
| Rated operation power at AC-4, 400 V |
7kW |
| Rated operation power NEMA |
14.9kW |
| RoHS-compliant |
Yes |
| Suitable for distribution board |
FALSE |
| Type of electrical connection of main circuit |
Screw connection |
| Voltage type for actuating |
AC |
| Width |
45mm |
