Eaton 276259 Main switch 2-pin 20A 240V AC circuit breaker switch

Eaton manufactures the Main switch with a 2-pin configuration, rated at 20 A for two breakers. It supports 240 V AC, making it suitable for residential and light industrial applications. The Eaton 276259 model is ideal for ensuring safe electrical operations.

Type	Main switch
Built-in depth	69.5mm
Colour calotte	Other
Degree of protection (IP)	IP40
Forced segregation according to DIN VDE 0113	FALSE
Imprint/indication	Symbol "arrows"
Lamp socket	Other
Lamp Type	Other
Max. lamp power	0W
Min. rated voltage	240V
Nominal current	20A
Nominal current - rounded value	20A
Nominal voltage	240V AC
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	2
Number of contacts as normally open contact	2
Number of pins	2
Number of Poles	2
Rated Current	20A
Rated switching capacity	12.5kA
Rated voltage	415V
Short-circuit breaking capacity (Icw)	1kA
Switching function	Other
Voltage type	AC
Width in number of modular spacings	2
With signal lamp	FALSE
