Eaton 236100 PXL-D Circuit breaker 1-pin 16A 230V AC LS-switch

The Eaton 236100 PXL-D16/1 is a circuit breaker designed to handle a current of 16 A at 230 V AC for reliable protection against overloads. It is a single-pole device ideal for residential and commercial electrical installations. This circuit breaker ensures safety and efficiency in protecting electrical circuits from damage.

Type	Circuit breaker
Current Rating	16A
Voltage Rating - AC	230V AC
No. of Poles	1
Tripping Characteristics	D
Additional equipment possible	TRUE
Ambient temperature during operating	-25-55°C
Built-in depth	70.5mm
Concurrently switching neutral conductor	FALSE
Connectable conductor cross section multi-wired	1-25mm²
Connectable conductor cross section solid-core	1-25mm²
Current limiting class	3
Current Ratng	16A
Degree of protection (IP)	IP20
Depth	70.5mm
Explosion-proof	FALSE
Flush-mounted installation	FALSE
Frequency	50-60Hz
Misc Attribute	Switchgear for domestic and commercial applications
Number of pins	1
Number of Poles	1
Number of poles (total)	1
Number of protected poles	1
Overvoltage category	3
Pollution degree	2
Power loss	2.3W
Rated impulse withstand voltage Uimp	4kV
Rated insulation voltage Ui	440V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	0kA
Switch-off Capacity	10kA
Voltage Rating	230V
Voltage type	AC
Weight	0
Width in number of modular spacings	1
