Eaton 236061 PXL-C25/1 Circuit breaker 1-pin 25A 230V LS-Switch

Eaton
Order Code:

02-6328

Brand: Eaton MPN: 236061 EAN-13: 4015082360610
Qty Unit Price (Ex VAT)
1+ £12.91
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
3 available to back orderBack-order availability date - 10/01/2026

The Eaton circuit breaker PXL-C25/1 is a single-pole device designed for a current rating of 25 A at 230 V AC. It provides reliable protection against overcurrents and short circuits in electrical installations. This product is typically used in residential and commercial applications to ensure safe operation of electrical systems.
Type Circuit breaker
Current Ratng 25A
Additional equipment possible TRUE
Ambient temperature during operating -25-55°C
Built-in depth 70.5mm
Concurrently switching neutral conductor FALSE
Connectable conductor cross section multi-wired 1-25mm²
Connectable conductor cross section solid-core 1-25mm²
Current limiting class 3
Degree of protection (IP) IP20
Depth 70.5mm
Explosion-proof FALSE
Flush-mounted installation FALSE
Frequency 50-60Hz
Misc Attribute Switchgear for domestic and commercial applications
Number of Poles 1
Number of poles (total) 1
Number of protected poles 1
Overvoltage category 3
Pollution degree 2
Power loss 2.8W
Rated impulse withstand voltage Uimp 4kV
Rated insulation voltage Ui 440V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V 10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V 10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V 0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V 0kA
Release characteristic C
Release characteristics C
Switch-off capacity 10kA
Voltage Rating 230V
Voltage type AC
Width in number of modular spacings 1
