Eaton's CR2011008 remote switch operates at a nominal voltage of 8 V DC/AC with a maximum switching current of 20 A. This industrial relay module features a 1 maker and 1 breaker configuration, serving as a reliable component in various electrical systems. It is typically used in applications requiring robust switching capabilities and is available as a single piece.
| Type |
Remote switch |
| Additional equipment possible |
TRUE |
| Built-in depth |
60mm |
| Connection |
Screw terminal |
| Degree of protection (IP) |
IP20 |
| Dim |
(W x H) 18 mm x 60 mm |
| Factory colour |
White |
| Height |
60mm |
| Hum-free |
FALSE |
| IP rating |
IP20 |
| Max. incandescent lamp load |
1950W |
| Max. load fluorescent lamp |
910VA |
| Max. load fluorescent lamp (Duo circuit) |
1160VA |
| Max. load fluorescent lamp (parallel compensated) |
232VA |
| Misc Attribute |
CR2011008 |
| Nominal voltage |
8V DC/AC |
| Number of contacts as normally closed contact |
1 |
| Number of contacts as normally open contact |
1 |
| Rated excitation voltage |
6.8-8.8V |
| Rated operating voltage |
400-400V |
| Rated operation current |
20A |
| Slider for hand switch |
FALSE |
| Switching current (max.) |
20A |
| Switching voltage (max.) |
230V AC |
| Voltage type (excitation voltage) |
AC/DC |
| Voltage type (operating voltage) |
AC/DC |
| Width |
18mm |
| Width in number of modular spacings |
1 |
| With day/night function |
FALSE |
