Eaton 182954 M30C Pushbutton switch round chrome-plated Blue

The Eaton 182954 Pushbutton switch features a chrome-plated, round design with a blue actuator, offering durability and an aesthetically pleasing appearance. Suitable for industrial control panels, this pushbutton is ideal for applications requiring a reliable and visually distinct control interface. With its robust construction, the Eaton switch is perfect for use in environments demanding frequent operator interaction.

Type	Pushbutton switch
Button Ø	35.39mm
Colour	Blue
Colour button	Blue
Colour front ring	Titanium
Connection	Screws
Construction type lens	Round
Degree of protection (IP), front side	IP67/IP69K
Degree of protection (NEMA), front side	4X, 13
Dim	(L x W x H) 28.95 x 36 x 46 mm
Factory colour	Blue
Front panel thickness	5.5mm
Functions	latch
Height	46mm
Height opening	0mm
Hole diameter	30.5mm
Labelled	FALSE
Length	28.95mm
Material front ring	Metal
Max. temperature	+70°C
Min. temperature	-25°C
Misc Attribute	M30C-FDRL-B
Number of command positions	1
Spring-return	FALSE
Suitable for lighting	TRUE
Switching function latching	TRUE
Type of button	Flat
Width	36mm
Width opening	0mm
With front ring	TRUE
With protective cover	FALSE
