The Doepke 09914293 circuit breaker, rated at 16 A, ensures reliable electrical protection in residential and commercial installations. With a 3-pin design and a 6 kA breaking capacity, it operates at both 230 V and 400 V. Typically used for overload and short circuit protection, this device is suitable for safeguarding circuits in a variety of electrical systems.
| Type |
Circuit breaker |
| Additional equipment possible |
true |
| Ambient temperature during operating |
-25 - 70°C |
| Built-in depth |
68mm |
| Concurrently switching neutral conductor |
false |
| Connectable conductor cross section multi-wired |
1.5 - 25mm² |
| Connectable conductor cross section solid-core |
0.5 - 25mm² |
| Current limiting class |
3 |
| Current Ratng |
16A |
| Degree of protection (IP) |
IP20 |
| Depth |
75.2mm |
| Dim |
(W x H x D) 53.1 x 83 x 75.2 mm |
| Explosion-proof |
false |
| Flush-mounted installation |
false |
| Frequency |
16.67 - 60Hz |
| Height |
83mm |
| Number of Pins |
3 |
| Number of poles (total) |
3 |
| Number of protected poles |
3 |
| Overvoltage category |
3 |
| Pollution degree |
2 |
| Power loss |
8.4W |
| Rated current |
16A |
| Rated impulse withstand voltage Uimp |
4kV |
| Rated insulation voltage Ui |
2000V |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V |
6kA |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V |
6kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V |
N/AkA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V |
N/AkA |
| Rated voltage |
400V |
| Release characteristic |
C |
| Release characteristics |
C/6kA |
| Voltage Rating |
230 V
400V |
| Voltage type |
AC |
| Width |
53.1mm |
| Width in number of modular spacings |
3 |
