Dehner Elektronik SPS G018-24 Industrial PSU 24V DC 0.75A 18W

Image Representative of Range

Dehner Elektronik SPS G018-24 Industrial PSU 24V DC 0.75A 18W

Dehner Elektronik
Order Code:

02-4707

Brand: Dehner Elektronik MPN: SPS G018-24 EAN-13: 4251125203012
Qty Unit Price (Ex VAT)
1+ £27.78
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
3 available to back orderBack-order availability date - 13/01/2026

Dehner Elektronik manufactures the SPS G018-24, which is an industrial power supply unit delivering 24 V DC at 0.75 A, with a total output of 18 W. This PCB mount PSU features solder lugs for easy integration in circuit board applications. It is suitable for industrial environments where a reliable and compact power supply is essential.
Output Voltage 24V DC
Output Current 0.75A
Power Rating 18W
Number of Outputs 1
Input Voltage 264V AC
Connection Screw terminal
Dimensions (L x W x H) 75 x 51 x 28 mm
Height 28mm
Length 75mm
Max. operating temperature (derating) 70°C
Min. input voltage 85V AC
Min. operating temperature (derating) -20°C
Min. temperature 85°C
Misc Attribute 1 Switched PSU
Misc Attribute 3 closed
MTBF 6263000h
Operating temperature (max.) 50°C
PSU features Regulated
Type Industrial PSU
Width 51mm
