DEGSON DG381-3.81-03P-14-00AH-1 Screw Terminal 3 Pins 1.31mm² Green

Image Representative of Range

DEGSON DG381-3.81-03P-14-00AH-1 Screw Terminal 3 Pins 1.31mm² Green

Degson
Standard range
Order Code:

02-4433

Brand: Degson MPN: DG381-3.81-03P-14-00AH-1
Qty Unit Price (Ex VAT)
1+ £0.477
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
481 in stock, despatched in 4 working days

The DEGSON DG381-3.81-03P-14-00AH-1 is a green screw terminal block supporting 1.31 mm² wire, designed with three pins. This modular terminal offers secure connections for printed circuit boards. It is typically used in applications such as lift systems, providing reliable and secure electrical conductivity.
No. of rows 1
Actuation direction Perpendicular (to the PCB)
AWG (min.) 26
AWG max. 16
Connector orientation Parallel (to the PCB)
Contact material Brass tin plated
Cross section (flexible) (max.) 1.31mm²
Cross section (flexible) (min.) 0.12mm²
Cross section (inflexible) (max.) 1.31mm²
Cross section (inflexible) (min.) 0.12mm²
CS 3.81mm
Enclosure material Polyamide 6.6
Factory colour Green
Height 12.10mm
Length 7.40mm
Manufacturer part # DG381-3.81-03P-14-00AH-1
Min. stripping length 5mm
Misc Attribute DG381-3.81-03P-14-00AH
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Number of pins 3
Pins per row 3
Series DG127
Stripping length (max.) 5mm
Type Screw terminal
Weight 1.55g
Width 11.43mm
Wire protection Yes
