DEGSON DG250-3.5-03P-11-01AH-1 Terminal Spring-loaded 3 Pins Grey

Image Representative of Range

DEGSON DG250-3.5-03P-11-01AH-1 Terminal Spring-loaded 3 Pins Grey

Degson
Standard range
Order Code:

02-4403

Brand: Degson MPN: DG250-3.5-03P-11-01AH-1
Qty Unit Price (Ex VAT)
1+ £0.301
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
526 in stock, despatched in 4 working days

The DEGSON DG250-3.5-03P-11-01AH-1 is a spring-loaded terminal with a conductor size of 0.82 mm² and three pins, designed for secure electrical connections. It features a robust grey housing suitable for various printed circuit board applications. This product is ideal for use in industrial and electronic systems requiring reliable and efficient terminal connections.
No. of rows 1
Actuation direction Perpendicular (to the PCB)
AWG (min.) 22
AWG max. 18
Connector orientation Perpendicular (to the PCB)
Contact material Phosphor bronze tin plated
Cross section (flexible) (max.) 0.82mm²
Cross section (flexible) (min.) 0.32mm²
Cross section (inflexible) (max.) 0.82mm²
Cross section (inflexible) (min.) 0.32mm²
CS 3.5mm
Enclosure material Polyamide 6.6
Factory colour Grey
Height 16.70mm
Length 12.00mm
Manufacturer part # DG250-3.5-03P-11-01AH-1
Min. stripping length 8mm
Misc Attribute DG250-3.5-03P-11-01AH
Nominal current 7A
Nominal current - rounded value 7A
Nominal voltage 300V
Number of pins 3
Pins per row 3
Series DG250
Stripping length (max.) 9mm
Type Spring-loaded terminal
Weight 1.65g
Width 12.00mm
Wire protection Yes
