DEGSON 2EDGVC-5.08-10P-14-00AH Socket Housing PCB 10 Pins 5.08mm Spacing

Image Representative of Range

DEGSON 2EDGVC-5.08-10P-14-00AH Socket Housing PCB 10 Pins 5.08mm Spacing

Degson
Standard range
Order Code:

02-4302

Brand: Degson MPN: 2EDGVC-5.08-10P-14-00AH
Qty Unit Price (Ex VAT)
1+ £0.866
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
324 in stock, despatched in 4 working days

The DEGSON socket housing PCB, model 2EDGVC-5.08-10P-14-00AH, is a pluggable, multi-pin connector with 10 pins and a 5.08 mm contact spacing. Typically, used for connecting PCB terminals, this connector is ideal for Combicon plug-in terminal applications. Its key features include ease of use in complex electronic projects and reliable connection integrity.
Board contact surface Tin plated
Case material PA 66 UL94V-0
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system board-to-board
Connector type Socket, vertical vertical
Contact material Brass
CS 5.08mm
Dim (L x W x H) 7.80 x 52.20 x 16.10 mm
Factory colour Green
Height 16.10mm
Length 7.80mm
Manufacturer part # 2EDGVC-5.08-10P-14-00AH
Misc Attribute 2EDGVC-5.08-10P-14-00AH
No. of rows 1
Nominal current 15A
Nominal current - rounded value 15A
Nominal voltage 300V
Pins per row 10
RoHS-compliant Yes
Total number of pins 10
Type Socket housing PCB
Width 52.20mm
