DEGSON 2EDGKD-5.08-08P-14-00AH-1 Pin Housing 8 Pins 5.08mm Spacing

Image Representative of Range

DEGSON 2EDGKD-5.08-08P-14-00AH-1 Pin Housing 8 Pins 5.08mm Spacing

Degson
Standard range
Order Code:

02-4281

Brand: Degson MPN: 2EDGKD-5.08-08P-14-00AH-1
Qty Unit Price (Ex VAT)
1+ £2.53
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
218 in stock, despatched in 4 working days

DEGSON offers a pin housing cable with 8 pins and a contact spacing of 5.08 mm, known as model 2EDGKD-5.08-08P-14-00AH-1. This component features pluggable, spring-loaded terminals which are ideal for quick and secure electrical connections. It is commonly used in printed circuit boards and other electronics requiring reliable PCB terminals.
No. of rows 1
AWG (min.) 26
AWG max. 12
Case material PA 66 UL94V-0
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Plug, straight
Contact material Phosphor bronze tin plated
CS 5.08mm
Dim (L x W x H) 23.70 x 40.64 x 15.00 mm
Factory colour Green
Height 15.00mm
Length 23.70mm
Manufacturer part # 2EDGKD-5.08-08P-14-00AH-1
max. cross section 2.5mm²
Max. temperature +105°C
Min. cross section 1mm²
Min. temperature -40°C
Misc Attribute 2EDGKD-5.08-08P-14-00AH-1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 8
RoHS-compliant Yes
Stripping length (max.) 10.00mm
Total number of pins 8
Type Pin housing cable
Width 40.64mm
