DEGSON 15EDGRC-3.5-05P-14-00AH Socket Housing 5 Pins 3.5mm Spacing

Image Representative of Range

DEGSON 15EDGRC-3.5-05P-14-00AH Socket Housing 5 Pins 3.5mm Spacing

Degson
Order Code:

02-4213

Brand: Degson MPN: 15EDGRC-3.5-05P-14-00AH EAN-13: 2050003394598
Qty Unit Price (Ex VAT)
10+ £0.434
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
282 available to back orderBack-order availability date - 10/01/2026

The DEGSON socket housing PCB, model 15EDGRC-3.5-05P-14-00AH, is a pluggable, multi-pin connector with a total of 5 pins and a contact spacing of 3.5 mm. This basic housing is equipped with Combicon plug-in terminals, making it ideal for use in printed circuit board applications. It's typically used in various electronic and electrical systems to facilitate reliable connections.
No. of Rows 1
Current Rating 8A
Colour Green
Board contact surface Tin plated
Case Material PA 66 UL94V-0
Compatible with (details) 15EDGK-3.5-05P-14-00AH
Connection Print
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system board-to-board
Connector Type Socket, horizontal mount
Contact Material Brass
CS 3.5mm
Dim (L x W x H) 9.20 x 18.30 x 7.00 mm
Height 7.00mm
Length 9.20mm
Nominal Voltage 300V
Pins per row 5
Total number of pins 5
Type Socket housing PCB
Width 18.30mm
