DEGSON 15EDGKR-3.81-08P-14-00AH Pin Housing Cable 8 Pins 3.81mm Spacing

Image Representative of Range

DEGSON 15EDGKR-3.81-08P-14-00AH Pin Housing Cable 8 Pins 3.81mm Spacing

Degson
Standard range
Order Code:

02-4200

Brand: Degson MPN: 15EDGKR-3.81-08P-14-00AH
Qty Unit Price (Ex VAT)
1+ £1.93
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
163 in stock, despatched in 4 working days

The DEGSON pin housing cable features eight pins with a contact spacing of 3.81 mm. It is a pluggable screw terminal suitable for lift systems and various electrical applications. As a versatile component, it can be used in combicon PCB terminals and plug-in terminals.
No. of rows 1
AWG (min.) 28
AWG max. 16
Case material PA 66 UL94V-0
Compatible with (details) 15EDGK-3.81-08P-14-00AH
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Plug, straight
Contact material Phosphor bronze
CS 3.81mm
Dim (L x W x H) 17.90 x 31.27 x 11.10 mm
Factory colour Green
Height 11.10mm
Length 17.90mm
Manufacturer part # 15EDGKR-3.81-08P-14-00AH
max. cross section 1.5mm²
Min. cross section 1mm²
Misc Attribute 15EDGKR-3.81-08P-14-00AH
Nominal current 8A
Nominal current - rounded value 8A
Nominal voltage 300V
Pins per row 8
RoHS-compliant Yes
Stripping length (max.) 7.00mm
Total number of pins 8
Type Pin housing cable
Width 31.27mm
