Crydom SPFE240D25 Solid State Relay 280V AC 25A 15 to 32V DC

Crydom
Standard range
Order Code:

49-4063

Brand: Crydom MPN: SPFE240D25 EAN-13: 2050000815751
Qty Was Unit Price (Ex VAT)
1+ £28.37   £20.54
10+    £19.57
20+    £19.46
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
32 in Stock, despatched in 4 days

This 25A solid state relay has an operating voltage of 12 to 280V AC and a control voltage of 15 to 32V DC. The SSR features an integrated heatsink design that provides excellent thermal management. The relay has an optically separated SCR output and also features low leakage current in off-state mode and high peak current, making it suitable for a wide range of heavy industrial applications.


  • Single inline package
  • Zero cross turn-on
  • SCR output for heavy industrial loads
  • Thermally conductive epoxy encapsulation
  • UL Approval
Height 23mm
Length 58.4mm
Mounting Type PCB
Width 45.7mm
Contact Configuration SPST-NO
Coil Current 15mA
Coil Voltage (DC) 32V
Impedance 1500Ω
Switching Current Max 25A
Switching Voltage Max (AC) 280V
Weight 25g
