Comatec PSM46024 Rail PSU DIN 24V DC 2.5A 60W 1 piece Building Automation

Image Representative of Range

Comatec PSM46024 Rail PSU DIN 24V DC 2.5A 60W 1 piece Building Automation

Comatec
Order Code:

11-6298

Brand: Comatec MPN: PSM46024 EAN-13: 4016138630855
Qty Unit Price (Ex VAT)
1+ £38.74
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
11 in stock, despatched in 4 working days

The Comatec PSM46024 is a DIN rail-mounted power supply unit providing 24 V DC at 2.5 A with a power output of 60 W. It features a compact design measuring 105x66.5x93mm and comes in grey RAL 7035, suitable for industrial applications. Typical uses include powering transformers, current transformers, and other industrial power systems.
Type Rail mounted PSU (DIN)
Output Voltage 24 - 28V DC
Ambient temperature -5 - +50°C
Connection Screw terminal
Depth 93mm
Dim (W x H x D) 105 x 66.5 x 93 mm
Frequency 48 - 63Hz
Height 66.5mm
Input Voltage 100 - 240 V~
Input voltage (max.) 264V AC
Max. output current 2.5A
Max. temperature +50°C
Min. input voltage 90V AC
Min. temperature -5°C
Misc Attribute 1 6 M (TE)
Output current (max.) - rounded 2.5A
Output voltage (min.) 23.28V DC
Output voltage (nominal) 24V DC
Power 60W
Primary Voltage 100 - 240 V~
Standards EN60950 / EN55022/B / EN61000-4
Width 105mm
