Cimco 180290 Blade Terminal 6.3mm Width 0.8mm Thick Red 1 piece

Image Representative of Range

Cimco 180290 Blade Terminal 6.3mm Width 0.8mm Thick Red 1 piece

Cimco
Standard range
Order Code:

11-5966

Brand: Cimco MPN: 180290 EAN-13: 2050001251305
Qty Unit Price (Ex VAT)
1+ £0.139
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
920 in stock, despatched in 4 working days

The Cimco 180290 is a crimp connector classified as a blade terminal with a width of 6.3 mm and a thickness of 0.8 mm. This red, partially insulated connector is designed for secure and reliable connections, suitable for electrical and automotive applications. Its standard size allows for compatibility with a wide range of electrical components and systems.
Connection angle 180°
Connector thickness 0.8mm
Connector width 6.3mm
Contact material Brass tin plated
Cross section 0.5 - 1mm²
Cross-section range 0.50 - 1 mm²
Factory colour Red
Insulation Halogen-free PA insulation (polyamide, nylon)
Insulation material PA 6.6
Insulation type Partially insulated
Material (details) Material: CuZn (brass)
max. cross section 1mm²
Min. cross section 0.50mm²
Misc Attribute 1 6.3 x 0.8 mm
RoHS-compliant Yes
Size 6.3 x 0.8 mm
Support sleeve Yes
Temperature range -60 - +105°C
Type Blade terminal
