Chint 782017 NL210 RCCB 25A 300mA 1P 10kA Protects Against Faults

The Chint 782017 is a residual current circuit breaker offering 25 ampere capacity and 300 milliampere sensitivity. Manufactured by Chint, it is designed for protecting electrical circuits from overloads and faults. This RCCB is suitable for residential and commercial electrical protection applications.

Type	RCCB
Tripping Characteristics	B Curve
Colour	Blue, White
Current Ratng	25A
Depth	79mm
Differential current rating	0.3A
Dim	(W x H x D) 54 x 91 x 79 mm
Height	91mm
Misc Attribute	B
Number of pins	1
Number of Poles	1
Switch-off Capacity	10kA
Voltage Rating	240V
Width	54mm
