Celsa 70030-1016 AST 315 Current Transformer, 150/5A, Compact Design

The Celsa AST 315 150/5A 3.75VA Kl. 1 is a current transformer designed for precise current conversion applications. Manufactured by Celsa, it accommodates a primary current of 150 A, with a secondary current of 5 A, featuring a line feed-through size of 33 x 33 mm and a diameter of 28 mm. This component is typically used in electrical systems for accurate current measurement and monitoring within a current loop.

Type	Current transformer attachment
Primary Current	150A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 150/5A 3.75VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	150A
Rated secondary apparent power	375VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
