Celsa 70030-1013-0250 AST 315 Current Transformer 200/5A Compact Design

The Celsa current transformer attachment, model number 70030-1013-0250, is designed for high accuracy with a primary current of 200 A and a secondary current of 5 A. Featuring a line feed-through of 33 x 33 mm and a diameter of 28 mm, it is optimal for integrating into small spaces within electrical systems. Typically used for precise current measurement and monitoring, this device is ideal for industrial and commercial electrical applications.

Type	Current transformer attachment
Primary Current	200A
Accuracy Class	1
Calibrated	FALSE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	AST 315 200/5A 2.5VA Kl. 1
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	200A
Rated secondary apparent power	25VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
