Celsa 70017-4241-0500 EAST315 Current Transformer, 400/1A, 5VA, PTB approved

The Celsa EAST315 400/1A 5VA Kl. 0.5 current transformer attachment is manufactured by Celsa. It features a primary current of 400 A and a secondary current of 1 A, with line feed-through dimensions of 33 x 33 mm. This current converter, suitable for precise measurement and monitoring applications, is ideal for industrial and commercial electrical systems requiring accurate current flow assessment.

Type	Current transformer attachment
Primary Current	400A
Accuracy Class	0.5
Calibrated	TRUE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	EAST315 400/1A 5VA Kl. 0.5
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	400A
Rated secondary apparent power	5VA
Rated secondary current	1A
Secondary connection	Screw connection
Secondary current	1A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
