Celsa 70017-3814-0100 EAST315 Current Transformer, 150/5A, PTB Approved

The Celsa EAST315 150/5A 1VA Kl. 0.5 is a current transformer attachment designed to convert a primary current of 150 A to a secondary current of 5 A. With a line feed-through of 33 x 33 mm and a diameter of 28 mm, it is suitable for precise current measurement in electrical systems. This device is used in applications requiring accurate monitoring and control, contributing to efficient management of electrical networks.

Type	Current transformer attachment
Primary Current	150A
Accuracy Class	0.5
Calibrated	TRUE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	EAST315 150/5A 1VA Kl. 0.5
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	150A
Rated secondary apparent power	1VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
