Celsa 70017-1466-0500 EAST315 Current Transformer 400/5A 5VA Kl. 0.5 PTB-App

The Celsa EAST315 400/5A 5VA Kl. 0.5 current transformer attachment, model number 70017-1466-0500, is designed for converting a primary current of 400 A to a secondary current of 5 A. It features a line feed-through of 33 x 33 mm with a diameter of 28 mm. This device is typically used in electrical systems to facilitate current measurement and protection in various applications.

Type	Current transformer attachment
Primary Current	400A
Accuracy Class	0.5
Calibrated	TRUE
Height opening	16-33mm
Line feed-through (H x W)	33 x 33 mm
Line feed-through (H)	33mm
Line feed-through (W)	33mm
Line feed-through diameter	28mm
Misc Attribute	EAST315 400/5A 5VA Kl. 0.5
Model	Attachable current transformer
Number of primary inputs	1
Opening diameter	28mm
Overcurrent limiting factor	FS 5
Rated primary current	400A
Rated secondary apparent power	5VA
Rated secondary current	5A
Secondary connection	Screw connection
Secondary current	5A
Snap mounting	FALSE
Width opening	16-33mm
With contact protection	TRUE
With copper rail	FALSE
