CBI Electric QYD18U220B0 Circuit Breaker 20A 80V DC for Solar Systems

The CBI Electric QYD18U220B0 circuit breaker is designed for photovoltaic applications with a 20 A rating and 80 V DC capacity. This robust component ensures reliable overcurrent protection in solar power systems. Typically used in PV installations, it helps maintain electrical safety and system integrity.

Type	Circuit breaker
Current Rating	20a
Voltage Rating - DC	80V DC
Tripping Characteristics	D
Current Ratng	20A
Depth	74mm
Dim	(W x H x D) 13 x 97 x 74 mm
Height	97mm
Misc Attribute	QY-1D, U2, 20 A
Number of Poles	1
Suitable For	PV fuse
Voltage Rating	80V DC
Width	13mm
