Bourns 4605X-101-222Lf Resistor Ladder 2.2KΩ Tht Sip 5 0.2 W 1 Piece

Bourns 4605X-101-222LF is a precision resistor array renowned for its reliability in electronic circuits. This component, classified under resistor arrays and networks, features a resistor ladder configuration with a resistance value of 2.2 kO and is encapsulated in a SIP (Single Inline Package) format with five pins, designed for through-hole technology mounting. With a power rating of 0.2 W, the resistor array is suited for applications requiring compact and efficient resistance solutions, such as digital-to-analogue converters, pull-up/pull-down resistors in bus interfaces, and signal processing networks. The use of this component is ideal in various engineering applications where space conservation and precise resistance characteristics are critical, particularly in complex circuitry configurations.

Type	Resistor ladder
Resistance	2.2kO
Number of Resistor	4
Power Rating	0.2W
Tolerance	2%
Network Type	Commoned
Content	1
Dimensions	(L x W x H) 12.65 x 2.49 x 5.08 mm
Height	5.08mm
Length	12.65mm
Maximum Temperature	125°C
Temperature Coefficient	100ppm/°C
Width	2.49mm
