Bourns 3224W-1-103E Cermet trimmer linear 0.25 W 10 kΩ 4320 ° 1 pc

Bourns 3224W-1-103E is a high-precision cermet trimmer resistor engineered for applications requiring precise resistance adjustment. This linear trimmer, also known by the identifier 2996134, has a resistance of 10 kO and is capable of dissipating up to 0.25 watts of power, making it suitable for fine-tuning circuits as well as calibrating and adjusting electronic devices. The component offers a mechanical adjustment through a rotational range of 4320 degrees, providing detailed control over the resistance value in a compact, durable package. It is ideal for use in various engineering applications, including instrumentation, automation systems, and communication equipment, where accuracy and reliability are paramount.

Type	Cermet Trimmer
Resistance	10kΩ
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	2.5mm
Dimensions	(L x W x H) 4.8 x 3.5 x 5.3 mm
Electrical Angle	4320°
Height	5.3mm
Length	4.8mm
Maximum Temperature	150°C
Minimum Temperature	-65°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	3.5mm
