Block ST 1000/4/23 Control/Isolation/Safety Transformer 1000VA 380-420V

Image Representative of Range

Block ST 1000/4/23 Control/Isolation/Safety Transformer 1000VA 380-420V

Block
Standard range
Order Code:

01-6402

Brand: Block MPN: ST 1000/4/23
Qty Unit Price (Ex VAT)
1+ £168.67
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Block ST 1000/4/23 by Variac is a versatile transformer that can function as a control, isolation, or safety transformer. It has an input of 380 V to 420 V AC and outputs 230 V AC with a power capacity of 1000 VA. This transformer is ideal for automation systems and power management applications.
Connection Screw terminal
Design type open
Dim (L x W x H) 154 x 150 x 148 mm
Efficiency 94%
Fitting method Base plate
Frequency 50 - 60Hz
Height 148mm
Input voltage (number x voltage) 1 x 380 V AC, 400 V AC, 420 V AC
Insulation class VDE = B, UL = class 105
Length 154mm
Max. ambient temperature +40°C
Misc Attribute ST 1000/4/23
Mounting Type L-piece
No. of inputs 1
No. of outputs 1
Output voltage 230V AC
Output voltage (number x voltage) 1 x 230 V AC
Power 1000VA
Protection class I
RoHS-compliant Yes
Standards VDE, UL 5085-1/-2, CSA 22.2 NO. 66
Test mark cULus recognized
Type Control transformer
Weight 13.10kg
Width 150mm
