Block CUL500/1,00 Copper Wire Enamel-Coated 1mm Diameter 70m 0.50kg

The Block enamel-coated copper wire has an outside diameter of 1 mm, measures 70 metres in length, and weighs 0.50 kilograms. This wire is ideal for use in transformer windings and inductive coils due to its durable enamel coating. Manufactured by Block, this high-quality copper wire is suited for applications requiring reliable insulation and efficient conductivity.

AWG	Not Specified
Number of Cores	1
Conductor Stranding	1 Solid
Insulation Material	Insulating base: min. Polyurethane, mod.
Length	70m
Type	CUL 500
Cable Diameter	1mm
Current load capacity	2.8A
Max. temperature range (fixed installation)	+155°C
Max. temperature range (flexible installation)	+155°C
Packaged	Yes
Sold by Metre	No
Standards	IEC 60317-20
Surface	Polished
Temperature Range	+155°C
Weight	0.50kg
