Block CUL100/0.50 Copper Wire 0.50mm Dia 54m Enamel-Coated

Block enamel-coated copper wire, manufactured by Block, has an outside diameter of 0.50 mm and weighs 0.10 kg in a 54 m length. This insulative wire is commonly used in applications such as transformer coils and inductive coil wire assemblies. It is known for its durability and conductive properties in electrical applications.

AWG	Not Specified
Number of Cores	1
Conductor Stranding	1 Solid
Insulation Material	Insulating base: min. Polyurethane, mod.
Length	54m
Type	Enamel-coated copper wire
Cable Diameter	0.50mm
Current load capacity	0.70A
Max. temperature range (fixed installation)	+155°C
Max. temperature range (flexible installation)	+155°C
Packaged	Yes
Sold by Metre	No
Standards	IEC 60317-20
Surface	Polished
Temperature Range	+155°C
Weight	0.10kg
