Block CUL 100/1.12 Enamel-Coated Copper Wire 1.12mm x 11m 0.10kg

Block
Standard range
Order Code:

11-5007

Brand: Block MPN: CUL 100/1,12 EAN-13: 4016138670332
Qty Unit Price (Ex VAT)
1+ £6.21
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
12 in stock, despatched in 4 working days

The Block Enamel-coated copper wire, model 02050001050021, features an outside diameter of 1.12 mm. Weighing 0.10 kg and measuring 11 m in length, this wire is ideal for use as transformer or inductive coil wire. Manufactured by Block, it is suitable for applications requiring enamelled insulation, such as electrical coils and inductor designs.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 100
Certification marks IEC 60317-20
Current load capacity 3.5A
Halogen-free No
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
No. of leads 1
Outside diameter (w/o coating) 1.12mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.10kg
