Block CUL 100/0.40 Enamel-Coated Copper Wire, 0.40mm, 86m, 0.10kg

Block
Standard range
Order Code:

11-5001

Brand: Block MPN: CUL 100/0,40 EAN-13: 4016138670219
Qty Unit Price (Ex VAT)
1+ £6.52
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
54 in stock, despatched in 4 working days

Block enamel-coated copper wire has an outside diameter of 0.40 mm and weighs 0.10 kg for an 86-meter length. Manufactured by Block, this thin, insulated wire is ideal for use in inductive coil applications such as transformers. Its durable enamel coating provides excellent insulation and protection in electronic and electrical systems.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 100
Certification marks IEC 60317-20
Current load capacity 0.45A
Halogen-free No
Manufacturer part # CUL 100/0,40
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
Misc Attribute CUL 100/0,40
No. of leads 1
Outside diameter (w/o coating) 0.40mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.10kg
