Block CUL 100/0.35 Copper Wire 0.35mm Dia 112m Length Enamel-Coated

Block
Standard range
Order Code:

11-5000

Brand: Block MPN: CUL 100/0,35 EAN-13: 4016138670202
Qty Unit Price (Ex VAT)
1+ £6.68
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

The enamel-coated copper wire, manufactured by Block, has an outside diameter of 0.35 mm and weighs 0.10 kg over a length of 112 m. This thin coated wire is ideal for creating inductive coil wires and transformer winding applications. Its insulation and flexibility make it suitable for use in electrical and electronic circuitry.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 100
Certification marks IEC 60317-20
Current load capacity 0.35A
Halogen-free No
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
No. of leads 1
Outside diameter (w/o coating) 0.35mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.10kg
