Block CLI200/90 Enamel-Coated Copper Wire 0.10mm OD 36m 0.20kg

Block
Standard range
Order Code:

11-4995

Brand: Block MPN: CLI 200/90 EAN-13: 4016138670066
Qty Unit Price (Ex VAT)
1+ £26.52
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
6 in stock, despatched in 4 working days

Block manufactures enamel-coated copper wire with an outside diameter of 0.10 mm. The wire is 90 x 0.1 mm in size, measures 36 metres, and weighs 0.20 kg. It is typically used for inductive coil wire applications such as transformers, given its thin and insulated properties.
Insulation material Polyurethane
Cable features Enameled
Cable type CLI 200
Certification marks IEC 6031 7-11
Core layout 90 x 0.1mm
Cross section 1 x 0.707 mm²
Cross section (each core) 0.707mm²
Current load capacity 2.52A
Halogen-free No
Manufacturer part # CLI 200/90
Material (details) Electrolytic copper
Max. temperature range (fixed installation) +130°C
Max. temperature range (flexible installation) +130°C
Misc Attribute CLI 200/90
No. of leads 1
Outside diameter (incl. coating) 0.10mm
Packaged Yes
Sold per metre No
Surface Polished
Type Enamel-coated copper wire
Weight 0.20kg
