Binder 99 1632 814 04 Mini DIN Connector Straight 4 Pins 1pc

Image Representative of Range

Binder 99 1632 814 04 Mini DIN Connector Straight 4 Pins 1pc

Binder
Standard range
Order Code:

01-4750

Brand: Binder MPN: 99 1632 814 04

  • Quickly find another product in this range by Manufacturer part #:

    99 1632 812 04 99 1632 814 04
Qty Unit Price (Ex VAT)
1+ £21.24
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
20 in stock, despatched in 4 working days

The binder 99 1632 814 04 is a Mini DIN connector with a straight configuration. It features a total of four pins and is supplied as a single piece. Typically, this connector is used in audio, video, and data transmission applications.
AWG 16
Case material PA
Connection Screws
Connection angle 180°
Connector type Connector, straight
Contact material CuZn
Cross-section range 1.50 mm² (min)
IP rating IP67
Manufacturer part # 99 1632 814 04
Max. temperature +85°C
Min. cross section 1.50mm²
Min. temperature -40°C
Misc Attribute Binder
Nominal current 12A
Nominal current - rounded value 12A
Nominal voltage 63V
Number of pins 4
Seal Screws
Total no. of pins 4
Type Mini DIN connector
