Binder 09 0687 700 03 Mini DIN Connector Sleeve Plug 2 Pins

Name: Binder 09 0687 700 03 Mini DIN Connector Sleeve Plug 2 Pins
Brand: Binder
Price: 15.33 GBP
Availability: BackOrder

Extended range

Order Code:

01-4656

Brand: Binder MPN: 09 0687 700 03

RoHS Compliant
Country of Origin: Germany
Free UK shipping available
View Full Product Range (5)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£15.33

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

Available to back orderBack order, lead time 10 days

Product Details
Product Range
Data Sheets
Quick Quote

The binder 09 0687 700 03 is a Mini DIN connector featuring a sleeve plug with a total of 2 pins. Manufactured by binder, this connector is ideal for small-scale electronic connections. It is typically used in audio and video equipment or data transmission applications.

AWG	16
Case material	PA
Connection	Open end cable
Connection angle	180°
Connector type	Sleeve plug
Contact material	CuZn
Cross-section range	1.38 mm² (min)
Feature	S-coded
IP rating	IP68
Manufacturer part #	09 0687 700 03
Max. temperature	+85°C
Min. cross section	1.38mm²
Min. temperature	-40°C
Misc Attribute	Binder
Nominal current	16A
Nominal current - rounded value	16A
Nominal voltage	630V
Number of pins	2
Seal	Screws
Total no. of pins	2
Type	Mini DIN connector
