Binder 09 0453 300 14 Mini DIN Connector Sleeve Plug 14 Pins

Image Representative of Range

Binder 09 0453 300 14 Mini DIN Connector Sleeve Plug 14 Pins

Binder
Standard range
Order Code:

01-4645

Brand: Binder MPN: 09 0453 300 14
Qty Unit Price (Ex VAT)
1+ £13.13
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
18 in stock, despatched in 4 working days

The binder Mini DIN connector, model 09 0453 300 14, is a sleeve plug with 14 pins. This component is typically used in electronic devices requiring secure and compact connections. It's ideal for applications in audio-visual systems and computer peripherals.
AWG 24
Case material PBT, UL94V-0
Connection Soldering
Connection angle 180°
Connector type Sleeve plug
Contact material CuZn
Cross-section range 0.25 mm² (max)
IP rating IP67
Leading contact (PE) No
Manufacturer part # 09 0453 300 14
max. cross section 0.25mm²
Max. temperature +95°C
Min. temperature -40°C
Misc Attribute Binder
Nominal current 3A
Nominal current - rounded value 3A
Nominal voltage 60V
Number of pins 14
Seal Screws
Total no. of pins 14
Type Mini DIN connector
