Binder 09-0408 00-03 Female 3 Pin Rear Fastening with Solder Terminal

A 3-pin female silver subminiature rear fastening panel mount M9 screw connector with solder terminals.

• Number of poles: 3
• Connector locking system: Screw
• Termination: solder
• Wire gauge (mm): 0,25 mm²
• Wire gauge (AWG): 24
• Degree of protection: IP 67
• Mechanical operation: >500 mating cycles
• Upper temperature: +85 °C
• Lower temperature: -40 °C
• Rated voltage: 125 V
• Rated impulse voltage: 1500 V
• Pollution degree: 1
• Overvoltage category: II
• Material group: III
• Rated current (40°C): 4 A
• Volume resistivity: ≤ 3 mΩ
• Material of contact: CuSn (bronze)
• Contact plating: Au (gold)
• Material of contact body: PA (UL 94 V-0)
• Material of housing: CUZn (brass nickel plated)

Type	Panel Mount Female
Number of Contacts	3
Connector Size	20 mm dia
Gender	Female
Contact Material	CuSn
Contact Plating	Gold
Current Rating	4A
IP Rating	IP67
Maximum Temperature	+80°C
Min. temperature	-40°C
Nominal Voltage	125V
Number of pins	3
Termination	Solder
