Binder 09 0115 320 05 Mini DIN Connector Sleeve Plug 5 Pins

The binder Mini DIN connector, part number 09 0115 320 05, features a sleeve plug with a total of 5 pins. Manufactured by binder, this connector is commonly used in audio, video, and data transmission applications. Its compact design ensures reliable performance in various electronic devices and equipment.

Mounting Type	Termination
Plug / Socket	Plug
No. of Contacts	5
AWG	22
Connection Angle	180°
Connector Body Material	PBT, UL94V-0
Contact Material	CuSn
Max. temperature	+85°C
Min. temperature	-30°C
Nominal Current	5A
Nominal current - rounded value	5A
Nominal Voltage	300V
Number of Ways	5
Seal	Screws
Termination	Open end cable
Total no. of pins	5
Type	Sleeve plug
