The Bernstein 6075685097 Safety button is a robust emergency power off switch designed for industrial safety applications. As a main switch from Bernstein, it provides reliable and quick power disconnection in emergencies. Typical uses include machinery shutdowns and emergency stop functions in factory settings.
| Type |
Safety button |
| Ambient temperature |
-25-70°C |
| Coating housing |
Uncoated |
| Construction type housing |
Cuboid |
| Cross-/short circuit identification possible |
TRUE |
| Degree of protection (IP) |
Other |
| Degree of protection (NEMA) |
4 |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Height of sensor |
15mm |
| Housing Material |
Plastic |
| Length of sensor |
36mm |
| Max. output current at protected output |
100mA |
| Mechanical mounting condition for sensor |
Other |
| Misc Attribute |
SRF-4/2/1-E0,25-U |
| Number of contact energized outputs with signalling function |
0 |
| Number of protected contact energized outputs |
0 |
| Number of protected semiconductor outputs |
2 |
| Number of semiconductor outputs with signalling function |
1 |
| Performance level according to EN ISO 13849-1 |
Level e |
| Protected switch distance OFF |
25mm |
| Protected switch distance ON |
10mm |
| Rated supply voltage DC |
24-24V |
| SIL according to IEC 61508 |
3 |
| Suitable for safety functions |
TRUE |
| Switching distance |
13mm |
| Type of actuation |
Transponder |
| Type of electric connection |
Cable with connector |
| Type of switching output |
PNP |
| Voltage type |
DC |
| Width sensor |
26mm |
| With monitoring function downstream switching devices |
FALSE |
| With status indication |
TRUE |
