BACO 100641-GN L22EM20 Kill Switch Mushroom Head Green 40mm

Manufactured by Baco, the 100641-GN L22EM20 is a black and green kill switch with a PVC front ring and a turn mechanism. This mushroom head illuminated switch has a 40mm diameter for easy emergency access. It is typically used in machinery to safely disconnect power in case of an emergency.

Type	Kill switch
Switch Function	Latch
Voltage Rating	N/A
Current Rating	N/A
(Ø)	40mm
Bulb Type	LED (monochrome)
Button Ø	40mm
Colour	Green
Connection	External contact
Dim	(Ø x H) 40 mm x 25.7 mm
Factory colour	Green
Height	25.7mm
IP Rating	IP69K
Lighting Type	Area illumination
Misc Attribute 1	Unlocking by pressing turn
Misc Attribute 2	L22EM20
Print motif	None
Recess Diameter	22.3mm
Unlocking mechanism	Turn
