ATE Electronics RB25/7-3R0-J Power Resistor Grey Ceramic 25W 3 Ohm

ATE Electronics RB25/7-3R0-J is a robust power resistor designed for high-performance applications requiring precise resistance values and durability. This grey ceramic resistor features a resistance value of 3 ohms and is engineered to handle a power rating of up to 25 watts, making it suitable for high power applications where thermal stability and high impedance management are critical. The resistor is constructed using resistance wire technology encased in a durable ceramic housing, ensuring efficient heat dissipation and reliability under varying electrical loads. It is typically used in industrial equipment, power supplies, and electronic circuits where consistent performance and reliability are essential.

Type	High power resistor
Resistance	3Ω
Power Rating	25W
Content	1
Dimensions	(L x W x H) 69 x 27.7 x 14 mm
Height	14mm
Insulation Resistance	10000MΩ
Length	69mm
Maximum Temperature	250°C
Minimum Temperature	-55°C
Product Type	High power Resistor
Temperature Coefficient	50ppm
Threshold Voltage	550
Tolerance ±	5%
Width	27.7mm
