Aim-TTi QL355T SII Power Supply Triple Output

The QL series uses pure linear technology and offers unrivalled performance in terms of regulation, output noise and dynamics. Line and load regulation are close to the limit of measurement. Recovery time from transient current pulses is better than 50µs. Output noise is less than 350µV rms in CV mode and down to 20µA rms in CI mode, dramatically better than other PSUs

The user interface of the QL series has been painstakingly designed to provide rapid control while guarding against any possibility of error. Unlike other digitally controlled units, the QL series provides both numeric and rotary control. Illuminated keys and display legends provide instant confirmation of settings and status.

For those preferring quasi-analogue control, or for applications where the voltage or current must be gradually changed, the Jog wheel is available. The wheel has a positive stepped action but can be spun rapidly when required. Output voltage can be incremented or decremented in steps of 0.1V, 10mV or 1mV. Current steps can be selected from 0.1A down to 0.1mA. The Jog function can be left permanently engaged or can be disabled at the touch of a button.

• Cooled by temperature-controlled fan
• Simultaneous voltage and current readout
• Voltage and current step less adjustment
• Constant voltage or constant current operation
• Overvoltage protection
• Protection against reverse polarization
• LOCK function (settings lock)
• Coarse and fine voltage adjustment
• Manufacturers part no. Aim-TTi QL355T SII

Not recommended for use as a battery charger.
