1761284 - Mean Well SD-100A-12

The Mean Well SD-100A-12 is a DC/DC converter with a voltage rating of 12 V DC and a current rating of 8.5 A, providing 102 W of power. This power supply unit is suitable for use in railway, tram, and underground systems, conforming to railway standards. It is also applicable in in-car systems and automotive applications such as car chargers and charging cables.

Output Voltage	12V DC
Output Current	8.5A
Power Rating	102W
Number of Outputs	2
Input Voltage	180-264VAC
Connections	Screw terminals
Dimensions	(L x W x H) 199 x 98 x 38 mm
Efficiency	82%
Height	38mm
Length	199mm
Output	Screw terminals
Type	DC/DC converter
Weight	650g
Width	98mm
