Zettler Electronics AZ943-1AH-5DE PCB Relay 5V DC 15A 1pc

Zettler Electronics
Order Code:

08-3696

Brand: Zettler Electronics MPN: AZ943-1AH-5DE EAN-13: 2050006592687
Qty Unit Price (Ex VAT)
5+ £0.872
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
27 in stock, despatched in 4 working days

The Zettler Electronics AZ943-1AH-5DE is a PCB relay designed for use in printed circuit boards, operating at 5 V DC with a 15 A capacity. This mini relay is ideal for high-density mounting and is commonly used in automotive and industrial control applications. The single-pole single-throw configuration ensures reliable switching performance.
Coil Voltage 5V DC
Contact Configuration 1NO
Switching Current 15A
Coil Resistance 70Ω
Contact Material AgSnO2
Control Mode monostable, 1 coil
Dimensions (L x W x H) 19.00 x 15.30 x 15.70 mm
Durability 1 x 10E6
Height 15.70mm
Length 19.00mm
Max. pick-up Voltage 11.2V DC
Max. switching capacity 300W
Max. temperature +70°C
Min. pick-up Voltage 3.8V DC
Minimum Temperature -40°C
Mounting Type PCB
Response Time 10ms
Switching Voltage Max 30V DC
Type PCB relay
Width 15.30mm
