Zettler Electronics AZ943-1AH-12DEGW PCB Relay 12V DC 15A SPDT 1pc

Zettler Electronics
Order Code:

08-3691

Brand: Zettler Electronics MPN: AZ943-1AH-12DEGW EAN-13: 2050006598931
Qty Unit Price (Ex VAT)
5+ £1.04
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
4 in stock, despatched in 4 working days

The Zettler Electronics AZ943-1AH-12DEGW is a PCB relay designed for 12 V DC applications. It is a compact and reliable component, ideal for use in printed circuit boards. Typical applications include control systems and electronic devices requiring efficient switching.
Coil Voltage 12V DC
Contact Configuration 1NO
Switching Current 15A
Coil Resistance 400Ω
Contact Material AgSnO2
Control Mode monostable, 1 coil
Dimensions (L x W x H) 19.00 x 15.30 x 15.70 mm
Durability 1 x 10E6
Height 15.70mm
Length 19.00mm
Max. pick-up Voltage 26.8V DC
Max. switching capacity 300W
Max. temperature +70°C
Min. pick-up Voltage 9V DC
Minimum Temperature -40°C
Mounting Type PCB
Response Time 10ms
Switching Voltage Max 30V DC
Type PCB relay
Width 15.30mm
